SLN100 Nickel Reinforced 1mm - 1m x 1m
1mm Thick, 1m x 1m Sheet of Klinger SLN100 Nickel Reinforced Gasket Jointing
- Properties
- Max. Temperature : 500°C
- Max Pressure : 200 Bar
- Excellent resistance to steam
- Improved handling due to 0.013mm Nickel insert
- Resistant to virtually all media
- Outstanding resistance to high and low temperature
- High compressibility
- Good leakage properties
- Unlimited storage life
- Anti-stick finish on both sides
- Easy to cut
| Typical Specifications (Typical values for 1.5mm thick material) | ||
|---|---|---|
| Compressibility ASTM F 36 A | 40% | |
| Recovery ASTM F 36 A | 15% | |
| Stress Relaxation DIN 52913 | 50MPa, 16h/300°C | min 48MPa |
| Klinger cold/hot compression (50MPa) | Thickness decrease 23°C Decrease at 300°C |
40% 1.5% |
| Gas Leakage according to DIN 3535/6 | <0.5ml/min | |
| Chlorides (Soluble) | <40ppm | |
| Fluoride and Chloride Content | <200ppm | |
| Density of Graphite | 1.0g/cm³ | |
| Purity | min 98% | |
| Datasheets |
|---|
